The side panel shows you the currently loaded parts libraries and their contents. Protel has all the tools to do just that and more. In its purest form this is a matter of placing schematic Protel 99Se in a nutshell : Basic commands The zoom function will execute and you will find yourself in that area with the part of choice still attached. Upon completion you return to the previous command and continue where you left off there.Įxample Place Part, move cursor and do Zoom Window : draw the zoom area. You can stack up to 3 commands like this.
This means you can invoke a command while already in the process of executing a different one.
The status bar gives you information about the commands and their shortcuts at your disposal during almost every step you are taking. Place Part = P PPlace Wire = P WPlace Net = P NZoom WindowAnd so on. The rule here is: think what you want to do and type the 2 letters of that action. Most of these are easy to pick up and you will find them very valuable.
#Copyright symbol protel 99se windows#
However, There are additional hotkeys that follow the Protel way and do not conform to the standard windows way. Underlined letters on menus can be activate by holding down the ALT key and pressing that letter. Right click on them and you can change between icons, lists, details etc.Ĭommands and MenusProtel uses the standard windows approach of menus. TIP: The project manager and most popup boxes have a windows like view option. And finally waveform files are created by the simulator. These are created from with in the PCB module. PCB printers are definitions to create layer views. Spread sheets are excel 95 format files and can be edited using the built in spreadsheet program. These are created form inside the PCB layout tool. CAM files are the definitions to create manufacturing output for your project.
#Copyright symbol protel 99se pdf#
While you can import things like PDF files, Protel might not be able to open them.ĭocument types: Schematic and PCB are pretty obvious. Note : Keep in mind that Protel can only show the documents it recognizes. Importing documents or folders: Right click and select either import, import folder or import project. A wizard will pop up and show you the possible files you can create. Protel 99Se in a nutshell : Starting a projectĪdding files to your designTo add a document: simply right click on the whiteĪre of the project and select New.
#Copyright symbol protel 99se install#
A local copy of the drivers will beplaced Protels install directory. Especially if the new drivers have replaced some functions with new ones using a different format. Some programs install New versions of the ODBC drivers. Protel uses this engine to store and retrieve documents in the DDB file. ODBC is the database engine used by MS Access. When opening a design it will be converted to the windows file system. Note: Protel DXP no longer supports the MS Access database. Windows File systemStores all related documents in one directory.Pro: No problems with ODBC driver.Con: Lots of files. MS Access Database.This stores everything in one file.Pro: one file = one project. You can now set the location, name and design type. Protel 99Se in a nutshell : The environmentĬreating a new design is straightforward. It gives you hints on the things you can do Keep an eye on this when learning to know the tool. The Status BarsThis shows you coordinates, object properties, and hints. The Side PanelThis panel shows different information depending on the task at hand. The area can be split to show multiple parts of a design. It shows schematics, Layout, Simulation waveforms etc. The Main Work SurfaceThis is your working area.
